Power Inserter / Splitter TRIAX IFP-224 za Triax UFO antene

250,00 kn (~ 33,25 €)

IFP 224 PSU + Inserter 2 out 24V/200mA

TRIAX power supplies in elegant design.

F-connector on all inputs. Simple and easy installation. The 2 outputs are equipped with auto-terminated F connector meaning that there is no need to terminate an un-used output. Including a power supply / inserter to power a UFO antenna when used in a camping-car and powered from the 12V DC delivered from the camping-car.

  • 2 inputs, AC + DC 12V
  • Automatic switch from 12 VDC to 230V AC input upon availability
  • When connected to 230V AC, delivers 24V DC 200mA
  • When connected to camping-car 12V DC, delivers 12V DC 200mA
  • 1 x RF F-connector input
  • 2 x RF auto-terminated F-connector outputs for  2 x TV sets
  • Signal insertion loss: 4dB.
